Dry Type Single Screw Fish Food Pellet Making Machine 600kg/H

Product Categories
Henan Strongwin Machinery Equipment Co., Ltd.
Contact Now

Dry Type Single Screw Fish Food Pellet Making Machine 600kg/H

  • 1
  • 2

Brand Name : Strongwin

Model Number : DGP120B

Certification : CE,ISO,SGS

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000 sets per year

Delivery Time : 10-30 working days after deposit

Packaging Details : Wooden Case or In Container

Product name : Dry Type Single Screw Shrimp Fish Food Pellet Making Machine

Yield : 500-600kg/h

Main machine : crusher,mixer,extruder,dryer,spary,cooler machine

Application : Shrimp Fish food, pet food

Crusher capacity : 500-700kg/h

Dryer capacity : 200-400kg/h

Contact Now

DGP120B Dry Type Single Screw Shrimp Fish Food Pellet Making Machine

Introduction of Fish Food Pellet Making Machine

This fish feed pellet machine is suitable for making floating fish feed and other pet food with different shapes by changing different molds. The main material for making fish feed is maize powder and wheat flour. And we also can offer the whole line to making fish feed.

It mainly consists the following parts:raw material-crusher-mixer-extruder-dryer or cooler(dryer has better effects, if you want to save cost, had better choose dryer)-flavoring parts(selectable)-packer.

Advantages of Fish Food Pellet Making Machine

1. This fish feed extruder is widely used for producing floating feed pellets of all kinds of aquatic animal.
2. Advanced technology and humanized design ensures easy operation and reliable performance.
3. High efficiency, low power consumption
4. Screw sleeve of this fish feed extruder adopts enchase alloy steel strip structure, which guarantees long service life.
5. Different moulds can be chosen to make pellets with different diameters and shapes.
6. Feed pellets dia. Is 0.9-15mm.

Dry Type Single Screw Fish Food Pellet Making Machine 600kg/H

Technical Parameters of Fish Food Pellet Making Machine

Name Power (kw) Capacity (kg/h) Dimension(mm) Weight(kg)
Crusher 15 500-700 1600*1050*1300 320
Mixer 4.0kw 200kg/batch,Time:15 1650*1050*1450 350
DGP120-B floating machine Main power:55kw Feeder Power:1.1 cutter power:1.5 500-600 2400*1950*1600 1700
Dryer heating power:26-28kw;fan power:0.75kw;Mesh belt power:3.0kw 200-400 750*650*1850 150
counter-current cooler Fan power:4.0kw discharge method:pneumatic discharge 300-500kg/batch, Time is:20minutes 3500*1300*2400 1250
Quantity scale 1.1 ≤300bag/h;1-50kg/bag 2750*950*2940 586
Control system

Dry Type Single Screw Fish Food Pellet Making Machine 600kg/H
